Introducing the HTCN5x21.5 Welded Double Acting Hydraulic Cylinder, designed for exceptional performance in demanding applications. With a robust construction and high load capacity, this hydraulic cylinder guarantees reliability and efficiency for all your heavy-duty needs.
- Outer Diameter: 5.5 inches
- Rod Diameter: 2 inches
- Stroke Length: 21.5 inches
- Overall Length: 31.32 inches
- Extended Length: 50.87 inches
- Retracted Length: 29.37 inches
- Pressure Rating: 3500 PSI
- Column Load Capacity: 57,000 LBs
- Oil Volume: 7.31 QTs
- Rod Type: Chrome Plated
- Action: Double Acting
- Rod End Type: Pin Hole
- Ports: SAE 6
- Style: Welded
NOTE! Chrome-plated rod is NOT induction hardened (temperature treated). Possible bent rod is a result of misuse (incorrect measurements or type of application); such cases are not covered under warranty!
