Description
The CHARLOTTE PIPE FOUNDRY CO. PVC 00131 1200HA is a 4-inch PVC DWV pipe test cap with a spigot end, designed to temporarily seal drain, waste, and vent piping during pressure testing and rough-in construction phases. Manufactured in white PVC, it fits into Schedule 40 pipe and blocks the open end of the line to prevent debris, dirt, and foreign material from entering the system before final connections are made. Plumbers and pipefitters rely on this cap during new construction and remodel work to keep the drain system clean and test-ready.
This test cap is suited for residential and light commercial DWV applications where Schedule 40 PVC pipe is the specified material. It is commonly installed at the end of a 4-inch drain line stub-out during rough-in, allowing the system to be pressure- or air-tested before walls and floors are closed in. The spigot configuration inserts directly into a standard 4-inch Schedule 40 hub fitting or pipe end without the need for additional adapters.
Key Features
- Spigot end fits directly into 4-inch Schedule 40 PVC pipe or fittings
- Seals open pipe ends to prevent debris contamination during construction
- White PVC construction compatible with standard DWV solvent-cement joining
- Designed for use in drain, waste, and vent piping systems
- Sold in a package quantity of 50 units, suitable for multi-unit or large-scale rough-in projects
Compatibility
Designed as an OEM-style replacement and new-installation fitting for 4-inch Schedule 40 PVC DWV piping systems.
Installation Notes
Installation is performed by licensed plumbers or experienced pipefitters working on DWV rough-in. Solvent-cement the spigot end into a hub using a PVC primer and solvent cement rated for DWV applications, following local plumbing code requirements such as the IPC or UPC. Ensure the line is depressurized and dry before applying cement. Remove or cut out test caps before final system commissioning if permanent closure is not intended.
Technical Specifications
- Pipe Size: 4 inches
- End Type: Spigot
- Material: PVC
- Color: White
- Compatible Pipe Schedule: Schedule 40
- Application: DWV (Drain, Waste, Vent)
- Package Quantity: 50 EA
- Weight: 3.1 pounds
Standard Information
- Brand: CHARLOTTE PIPE FOUNDRY CO.
- Manufacturer Part Number: PVC 00131 1200HA
