Description
Discover the GP-F20-06-S9-A high pressure hydraulic gear pump, a reliable and durable solution for your hydraulic system needs.
Features:
- Constructed of an aluminum center section and cast iron end plates
- 11 displacement sizes ranging from 0.24 – 1.95 in3/rev. (4 – 32 cm3/rev)
- Standard mounting flange: SAE A – 2 bolt
- Standard drive shaft: 5/8” straight shaft with 5/32” key
- Recommended working conditions: Filtration: 25 micron or better, Oil viscosity: 7 – 700 cSt, Inlet Pressure: 12 – 32 psi absolute, Oil temp: -25° – 80°C (-12° – 175°F), Ambient: -22° – 55°C (-8° – 130°F)
Trust the GP-F20-06-S9-A for high pressure hydraulic applications, ensuring efficiency and performance in your machinery.
