Description
Discover the GP-F20-10-S9-C high-pressure hydraulic gear pump featuring an aluminium center section and cast iron end plates. This pump is designed for demanding applications that require reliable performance. With 11 displacement sizes ranging from 0.24 to 1.95 in3/rev (4 to 32 cm3/rev), the GP-F20-10-S9-C offers versatility and durability.
Key Features:
- Constructed of aluminium center section and cast iron end plates
- 11 displacement sizes available
- Standard mounting flange: SAE A – 2 bolt
- Standard drive shaft: 5/8” straight shaft with 5/32” key
- Recommended working conditions: Filtration: 25 micron or better, Oil viscosity: 7 – 700 cSt, Inlet pressure: 12 – 32 psi absolute, Oil temp: -25° – 80°C (-12° – 175°F), Ambient: -22° – 55°C (-8° – 130°F)
The GP-F20-10-S9-C is suitable for a wide range of industrial applications that demand high-pressure hydraulic power. Ensure reliable performance and efficient operations with this durable and versatile gear pump.
Take your hydraulic systems to the next level with the GP-F20-10-S9-C. Order now and experience exceptional performance and durability.
