Description
Constructed of an aluminum center section and cast iron end plates, the GP-F20-20-P1-C-BB is a high-pressure hydraulic gear pump with 11 displacement sizes ranging from 0.24 to 1.95 in³/rev (4 to 32 cm³/rev). The standard mounting flange is SAE A – 2 bolt, with a 5/8” straight shaft and 5/32” key. It is recommended to operate under specific working conditions: Filtration: 25 microns or better, Oil Viscosity: 7 – 700 cSt, Inlet Pressure: 12 – 32 psi absolute, Oil Temp: -25° – 80°C (-12° – 175°F), Ambient: -22° – 55°C (-8° – 130°F). Upgrade your hydraulic system with the GP-F20-20-P1-C-BB. Contact us for more details.
