Description
Constructed of an aluminum center section and cast iron end plates, the GP-F20-25-S11-C is a high-pressure hydraulic gear pump with 11 displacement sizes ranging from 0.24 to 1.95 in3/rev (4 to 32 cm3/rev). The standard mounting flange is a SAE A – 2 bolt, and the standard drive shaft is a 5/8” straight shaft with 5/32” key. This pump is designed for a wide range of hydraulic applications and offers reliability and durability.Recommended Working Conditions:- Filtration: 25 micron or better- Oil Viscosity: 7 – 700 cSt- Inlet Pressure: 12 – 32 psi absolute- Oil Temp: -25° – 80°C (-12° – 175°F)- Ambient Temp: -22° – 55°C (-8° – 130°F)Whether you need high-pressure performance or reliability in your hydraulic system, the GP-F20-25-S11-C is the ideal choice. Order yours today and experience top-notch hydraulic gear pump technology.
