Description
Constructed of an aluminum center section and cast iron end plates, the GP-F20-32-S9-A is a high-pressure hydraulic gear pump with 11 displacement sizes ranging from 0.24 to 1.95 in3/rev (4 to 32 cm3/rev). The standard mounting flange is a SAE A – 2 bolt, and the standard drive shaft is a 5/8” straight shaft with a 5/32” key. Additional shaft options are available as outlined in the Ordering Example.
Recommended working conditions:
- Filtration: 25 micron or better
- Oil Viscosity: 7 – 700 cSt
- Inlet Pressure: 12 – 32 psi absolute
- Oil Temp: -25° – 80°C (-12° – 175°F)
- Ambient: -22° – 55°C (-8° – 130°F)
The GP-F20-32-S9-A is a reliable and efficient hydraulic gear pump suitable for a variety of industrial applications. Its durable construction ensures long-lasting performance even under demanding conditions. Upgrade your system with the GP-F20-32-S9-A and experience high-pressure hydraulic power like never before.
Series Information: The GP-F20-32-S9-A belongs to the high-pressure hydraulic gear pump series known for its robust design and versatility. With a focus on performance and durability, the series is a top choice for industrial hydraulic systems.
Upgrade your hydraulic system with the GP-F20-32-S9-A and experience unrivaled power and reliability. Take advantage of its high-pressure capabilities and efficient design to enhance your industrial operations.
Don’t miss out on the opportunity to optimize your system with the GP-F20-32-S9-A high-pressure hydraulic gear pump. Purchase yours today and elevate your industrial applications to the next level.
