Description
Constructed of an aluminum center section and cast iron end plates, model GP-F20-08-P-C-BB is a high-pressure hydraulic gear pump with 11 displacement sizes from 0.24 – 1.95 in3/rev. (4 – 32 cm3/rev). The standard mounting flange is a SAE A – 2 bolt. The standard drive shaft is a 5/8” straight shaft with a 5/32” key. This model offers recommended working conditions including filtration of 25 microns or better, oil viscosity of 7 – 700 cSt, inlet pressure of 12 – 32 psi absolute, oil temperature of -25° – 80°C (-12° – 175°F), and ambient temperature of -22° – 55°C (-8° – 130°F). Ideal for various applications, this high-pressure hydraulic gear pump is a reliable choice for demanding hydraulic systems.
