Description
The PANDUIT CTAPR2/0-2-X is a C-style copper compression connector designed for making reliable, low-resistance electrical connections in wire termination and splicing applications. Built for copper conductors, this connector uses a compression-style installation method that creates a permanent, gas-tight joint. It is rated for 1 AWG conductor size. Electricians and electrical contractors working on power distribution, grounding systems, and feeder installations rely on this type of connector for code-compliant terminations that hold up in demanding service environments.
This connector is suited for use in commercial and industrial electrical installations where copper-to-copper conductor connections are required. Typical applications include panel feeder terminations, grounding electrode conductor splices, and utility service work. The C-style body profile allows for inline or tap connections depending on the installation configuration, making it a versatile choice for conduit and cable tray wiring systems.
Key Features
- C-style body profile supports inline and tap conductor connections
- Compression installation method creates a permanent, gas-tight joint
- Designed for use with copper conductors at 1 AWG
- Sold individually, one connector per unit
Compatibility
Designed as an OEM-style compression connector for copper conductor termination and splicing applications at 1 AWG wire size.
Installation Notes
Installation should be performed by a licensed electrician in accordance with NEC requirements for conductor terminations and splices. De-energize and lock out the circuit before beginning any termination work. A calibrated compression tool compatible with C-style connectors is required to achieve a proper, code-compliant crimp. Do not use this connector with aluminum conductors.
Technical Specifications
- Conductor Size: 1 AWG
- Connector Style: C-Style
- Conductor Material Compatibility: Copper
- Connection Method: Compression
- Unit of Measure: Each
- Quantity Per Package: 1
Standard Information
- Brand: PANDUIT
- Manufacturer Part Number: CTAPR2/0-2-X
