Description
The PANDUIT UTP28X5M-Q is a Category 6A unshielded twisted pair patch cord constructed with 28 AWG conductors. Designed to support 10 Gigabit Ethernet and other high-bandwidth network applications, this slimline patch cord delivers full Cat6A channel performance in a reduced-diameter form factor. The smaller conductor gauge allows for tighter bend radii and improved airflow in high-density patch panel environments. It is sold as a single unit and is suited for installation by low-voltage cabling technicians and structured cabling contractors working in data center, enterprise, and commercial network environments.
This patch cord is intended for use in high-density horizontal cabling and equipment room applications where cable management space is limited. The 28 AWG construction reduces cable bulk at patch panels and switch ports, making it well suited for top-of-rack switching deployments, server room cross-connects, and dense telecommunications rooms. Its Category 6A performance rating supports frequencies up to 500 MHz, meeting the bandwidth demands of modern switching infrastructure.
Key Features
- Category 6A performance rating supporting 10 Gigabit Ethernet applications
- 28 AWG slimline conductor construction reduces cable diameter and improves airflow
- Unshielded twisted pair design simplifies termination and routing
- Flexible jacket suitable for tight bend radius installations in high-density environments
- Sold individually as a single patch cord unit
Compatibility
Designed as an OEM-style Category 6A patch cord for use with standard RJ45 keystone jacks, patch panels, and network switches in structured cabling systems built to TIA-568 and ISO 11801 standards.
Installation Notes
Installation should be performed by a qualified low-voltage cabling technician following applicable structured cabling standards such as ANSI/TIA-568. Avoid exceeding the minimum bend radius of the cable jacket during routing and dressing. Do not apply excessive pulling tension during installation, as 28 AWG conductors are more susceptible to stretch-related performance degradation than standard 24 AWG patch cords. Confirm all connected equipment ports are rated for Cat6A channel performance before deploying in 10GbE applications.
Technical Specifications
- Category Rating: Category 6A
- Conductor Gauge: 28 AWG
- Cable Type: Unshielded Twisted Pair (UTP)
- Cable Length: 5 meters
- Unit of Measure: Each
- Quantity per Unit: 1
Standard Information
- Brand: PANDUIT
- Manufacturer Part Number: UTP28X5M-Q
